SATIS CO., LIMITED - your reliable partner for weighing products
9 Years
| Ask Lasest Price | |
| Brand Name : | SATIS |
| Model Number : | SAL600A 100-5000kg |
| Certification : | OIML |
| Price : | USD 30 - 100 per unit |
| Payment Terms : | T/T |
| Supply Ability : | 3000 units per month |
| Delivery Time : | 30 working days |
Features
Specification
| Maximum capacity (Emax) | kg | 100, 150, 200, 250, 300, 500, 750, 1000 | 1200, 1500, 2000, 3000, 5000 | |
| Rated output (Cn) | mV/V | 2,0 ± 0,002 | ||
| Accuracy | ±%FS | 0.03 | ||
| Max. number of intervals (nLC) | - | 3000 | ||
| Creep (30 minutes) | ±%FS | 0.02 | ||
| Zero balance | ±%FS | 1 | ||
| Temperature effect on zero balance (TCO) | ±%FS/10°C | 0.02 | ||
| Temperature effect on sensitivity (TC Span) | ±%FS/10°C | 0.02 | ||
| Safe overload | %FS | 120 | ||
| Ultimate overload | %FS | 150 | ||
| Nominal temperature range | °C | -10 ... + 40 | ||
| Operating temperature range | °C | - 30 ... + 70 | ||
| Input impedance | Ω | 400 ± 20 | ||
| Output impedance | Ω | 352 ± 3 | ||
| Insulation impedance | MΩ | ≥ 5000 | ||
| Recommended excitation | V DC/AC | 10 -12 | ||
| Excitation maximum | V DC/AC | 15 | ||
| Material | - | Alloy steel | ||
| Protection class | - | IP65 | IP68 | |
| Cable | - | Length: 5m; or customize special length to order; Diameter: Φ 5mm | ||
Wiring
The load cell is provided with a shielded 4 or 6 conductor cable. The shield will be connected or not connected to the load cell according to customer’s preference.
Dimension
100-1000kg:
1200-5000kg:
Accessories
No accessory is provided for standard shipment
|
|
